Features : With temperature compensated and linear correction / Physical quantity & temperature linear correction output by computer program / Industrial class sensor comes with high accuracy, long-term stability,and anti-condensation function.
Input : Capacitive Humidity Sensor & PT 100 Ω
Output : 0...20mA / 4...20mA／0...1VDC / 0...5VDC / 0...10VDC
linear accuracy ( at + 25 ℃ ) :
temp. ± 0.15 ℃ ± 0.002 ℃ x tactual /
dew point：± 3 dp ℃ ± ( 0.02 % F.S / ℃ ) /
temp. influence of body ( at + 25 ℃ ) : 0.02 % F.S. / ℃
Features :Speed Upgrade 150%
Input : Capacitive humidity sensor & PT 100 Ω
Output : Standard RS-485 & 1 analog output
Pressure resistance : 16 bar
Working range of dew point : -100 ... +60 dp °C
Linear accuracy : ±2 dp °C
Max. Scaling range : Dew point : -100 ... +60dp℃
